Product Description
1190 Adventure ALL steering stabilizer parts and kits for the 2013-2017 KTM 1190 Adventure All: the Scott's steering stabilizer, matched to the model years Scott's lists for this bike. On an adventure bike like the 1190 Adventure All, knobby tires, ruts and a loaded rear end can set off head shake; a steering stabilizer slows that side to side movement of the bars. For these years the sub mount complete kit is part DS-SUB-9164-01R (about 3.5 lb) and the sub mount mount kit only is part DM-SUB-9164-01R (about 3.5 lb); 1 more option are listed below.
Kit options for the KTM 1190 Adventure All (2013-2017)
- SUB Mount - Complete Stabilizer Kit - rubber type - using original triple clamp | part DS-SUB-9164-01R | about 3.5 lb
- SUB Mount - Mount Kit Only - rubber type - using original triple clamps | part DM-SUB-9164-01R | about 3.5 lb
- Frame Bracket only (Bolt-on Sub mount) | part FBD-9164 | about 0.56 lb
About this 1190 Adventure All listing
Scott's lists a single kit generation for the 1190 Adventure All, so this page covers every model year from 2013 to 2017. The part numbers on this page are DS-SUB-9164-01R, DM-SUB-9164-01R. Part DS-SUB-9164-01R is also used on 2 other Scott's models, so check the fit by model year and not by part number alone.
Technical Details
- Fits: KTM 1190 Adventure All, 2013-2017
- Also searched as: 1190 Adventure ALL stabilizer, 1190 Adventure ALL steering damper
- Stabilizer: the stabilizer on its own (part 4200-00) is the same on every bike; the mount kit is what changes by bike.
Fitment
- KTM 1190 Adventure All | 2013-2017 (2013, 2014, 2015, 2016, 2017)
Questions riders ask
Which kit do I need for the 1190 Adventure All?
If you do not have a Scott's stabilizer yet, pick a complete kit. If you already own one, a mount kit only moves it to this bike.
Will it fit my handlebars?
Check the bar diameter and the crossbar on your 1190 Adventure All. Scott's says some bikes need different bars when the crossbar sits too low.
Questions riders ask
Which Scott's steering stabilizer kit fits a KTM 1190 Adventure All?
Scott's lists 3 kit options for the KTM 1190 Adventure All (all years). Pick the one you want from the Kit menu on this page. A complete kit has everything you need to get a stabilizer on the bike; a mount kit only is for riders who already own a Scott's stabilizer. The kit guide has a chooser table.
What is the part number for a 1190 Adventure All steering damper from Scott's?
Scott's part numbers for the KTM 1190 Adventure All (all years):
- SUB Mount - Complete Stabilizer Kit - rubber type - using original triple clamp: part DS-SUB-9164-01R
- SUB Mount - Mount Kit Only - rubber type - using original triple clamps: part DM-SUB-9164-01R
- Frame Bracket only (Bolt-on Sub mount): part FBD-9164
Does a Scott's 1190 Adventure All steering damper kit come with the mounts?
The complete kit does. Scott's lists a complete kit as the one with everything you need to get a stabilizer on the bike, and a mount kit only as the part for riders who already own a Scott's stabilizer. Both are options for the KTM 1190 Adventure All on this page.
What does a 1190 Adventure All steering stabilizer do?
On an adventure bike like the 1190 Adventure All, knobby tires, ruts and a loaded rear end can set off head shake; a steering stabilizer slows that side to side movement of the bars.
Is the Scott's stabilizer for the 1190 Adventure All the same as on other bikes?
Almost always. The stabilizer is part 4200-00, and the mount is the part that changes from bike to bike. See the Scott's 4200-00 stabilizer.
Can I move my Scott's stabilizer to a KTM 1190 Adventure All?
Scott's says yes, with a mount kit for the new bike. For the KTM 1190 Adventure All, the mount kit only part: DM-SUB-9164-01R.
What is a tank slapper, and do I need a steering stabilizer on my KTM 1190 Adventure All?
A tank slapper is a fast side to side shake of the handlebars. Our guides explain what causes it and how to decide whether you need a stabilizer: tank slappers, speed wobble and head shake and do you need a steering stabilizer.
Will a Scott's steering stabilizer fit my KTM 1190 Adventure All?
Fit depends on the model year. This page covers all years of the KTM 1190 Adventure All. Choose your year in the fitment bar and match the part number on the kit to your bike. Part numbers are explained in the kit guide.
How do I set the damping on a 1190 Adventure All steering stabilizer?
Scott's says its off-road units damp as the bars turn away from center and let them return freely. Scott's also says the damping is adjustable, including while riding. The install guide covers settings.
How do I service a Scott's 1190 Adventure All steering stabilizer?
Scott's says to treat it like suspension, with an occasional oil change depending on how hard you ride. See the service guide.
